Ps:Please let us to know which carbon weave (UD/3K/12K/3K twill/12K
twill),finish(matt/glossy) you'd like when place your order.If haven't
message we'll just arrange UD/matt of the wheelset for you!
* Finish not only have supply normal matt/glossy,but also have supply paintless matt/paintless glossy (Newest upgraded production tech supply),paintless looks clear a bit than normal matt/glossy,near to the original suface,better appearance,and more environmental protection.
Basic info:
Rim Weight:
Novatec D411/D412sb hub,hubs axle size is:front 108x9mm and rear 145X10mm
(Front O.L.D=100mm,Rear O.L.D=130mm);
Disc brake with Six bolt/Center lock type quick release (QR)
front 108x9mm and rear 145X10mm
(Front O.L.D=100mm,Rear O.L.D=135mm);
Or thru axle hubs size is:front 100x12mm and rear 142X12mm (front
O.L.D=100mm,Rear O.L.D=142mm),
DT Swiss 350s/240s hubs size is:
Center lock type,and thru axle hubs size is:front 100x12mm and rear 142X12mm (front
O.L.D=100mm,Rear O.L.D=142mm),
Hub Weight:
Novatec D411 D412SB (Front:93g,Rear:232g)
DT Swiss 350s (Front:108g,Rear:214g)
DT Swiss 240S hub (Front:108g,Rear:265g)
Recommendation:
Max weight limit: 120kg
Max spoke tension: front: 110kgf rear:130kgf
Max tire pressure: 65psi.
Option hub details:
With Novatec D411/412SB hub:
With DT 350 hub:
With DT 240 EXP hub:
