Basic info:
Size:700C
Rim Width:25mm
Rim Depth: 65mm
Material:Toray 100% full carbon T700
Spoke:Five/5 spoke
Hub:Novatec
Tire Profile:Tubular/Clincher
Carbon Weave:UD/3K/12K/3K twill/12K twill
Finish:Matt/Glossy/Paintless Matt/Paintless Glossy
Warranty:2 years
Weight:
Tubular:
930±25g(front-road) 990±25g(Rear-road)
960±25g(front-fixed gear) 1010±25g(Rear-fixed gear)
Clincher:
930g±30(Front road),990g±30g(rear road)
1030g±30g(Front fixed gear),1120g±30g (Rear Fixed gear)
Logo painting:None,OEM logos or custom logos both available
Application: road bike/fixed gear bike are available
Standard:EN standard
PS:
Road bike V brake with Powerway quick release hubs axle size is:front 108x9mm and rear 140X10mm (front
O.L.D=100mm,Rear O.L.D=130mm);
Disc brake with Six bolt type Novatec quick release hubs axle size is:front 108x9mm and rear 145X10mm (front
O.L.D=100mm,Rear O.L.D=135mm);
Fixed gear with Novatec hub= Front O.L.D=100mm,Rear O.L.D=120mm.
PS:QR= quick release Powerway hubs size:front 108x9mm and rear 145X10mm (front O.L.D=100mm,Rear O.L.D=135mm)
Fixed gear hub= Front O.L.D=100mm,Rear O.L.D=120mm.
Recommendation:
Max weight limit: 120kg
Max tire pressure: 135psi
Feature:
Tech improvements:
* 700C 25mm width 65mm depth carbon five/5 spoke road bike/fixed gear wheels has excellent performances,it for advanced aerodynamics manufacture.It is ideally suited for racing ride.
* Finish not only have supply normal matt/glossy,but also have supply paintless matt/paintless glossy (Newest upgraded production tech supply),paintless looks clear a bit than normal matt/glossy,near to the original suface,better appearance,and more environmental protection.
* Filled with 3D weave, that will make the rim stable, safe and durable.
* Manufactured by new technology, the rims’ manufacturing process are without EPS bubbles, this means the rims are molded with a air bag that has the inner shape of the rim. Unlike the traditional technology, we don’t need to cut a lid to take out the bubbles. So the rim is complete, stronger and stiffer.
* 250Gpa modulus carbon fiber reinforcement strip gives additional stiffness on spoke holes.
